Acoustic Insight

Know every connector is seated the moment it’s installed.

AI Connector is a wrist wearable that mistake-proofs connector installs. It listens for the click of a connector seating, identifies that click in software, and tells the assembler straight away: OK, or not OK.

Connected to line control through ARCX, our line-side controller partner.

An assembler in dark work gloves plugs a wiring-harness connector into place in a vehicle’s engine bay. A screenless band on their wrist shows a green light.

The click is the only check, and nothing records it.

On most lines, the assembler listens for the click or feels it and moves on. Nothing records that it happened, and a connector that did not seat looks exactly like one that did.

It stays hidden until something fails downstream. Every step later costs more to fix.

Where a missed connector gets found

  1. At install

    Acoustic Insight confirms the click, and the assembler fixes it on the spot.

  2. End of line

    Found by test. The build goes back for rework and the schedule slips.

  3. After delivery

    Found by the customer. Warranty cost, and lost trust.

How AI Connector Pokayoke works

  1. The assembler seats the connector

    Work carries on the way it does today.

  2. The wearable listens and feels

    A microphone on the wrist picks up the click. A motion sensor picks up the push that goes with it.

  3. Software identifies the click

    An AI model is built to tell a seated connector from tool noise and other sounds, and to decide: seated, partly seated or not connected.

  4. The assembler knows straight away

    Light, screen and a chirp on the wrist say OK or not OK. The result goes to line control through ARCX.

Wearable feedIllustrative signal
SoundImpact tool, ignoredClick found
Hand motion

OK

Connector seated. The click matches a seated connector and the hand motion confirms the push.

Choose an install to replay it. The same noise runs in each, so you can see what changes when the click is weak or missing.

What changes on the line

The assembler gets the answer at the wrist

OK or not OK, in the moment, while the connector is still in reach. No waiting for end-of-line test.

Every connection leaves a record

Each click is logged against the build and the assembler, so quality can see what happened, not only what failed.

No cameras

The wearable works from sound and hand motion. Nothing is pointed at the assembler or at the product.

Connected to your line through ARCX

Acoustic Insight has partnered with ARCX. An ARCX controller is a compact PLC mounted line side. It is how Acoustic Insight connects into line control, and it is where all the build and assembler information comes from.

So every click is recorded against the right build and the right assembler.

Visit arcx.com(opens in a new tab)

Acoustic Insight

  • Wearable at the wrist
  • Software that identifies the click

Line-side controller

  • A compact PLC mounted line side
  • The integration into line control
  • The source of all build and assembler information

Line control

Your existing line control, with a record of every connector click.

When a connector doesn’t seat

The wearable catches it at the station. ARCX passes it to line control, and the line stops until a team leader has fixed it, so the build does not move on with the defect.

  1. Working

    1The assembler works

    Connectors are seated as usual, and the wearable checks every click.

  2. OKNot OK

    2A missed click is caught

    A connector that did not seat, or was missed, shows NOT OK on the wrist.

  3. ReadyDefect logged

    3ARCX gets the defect

    The wearable signals the ARCX line-side PLC, which records it against the build and the assembler.

  4. RunningLine stopped

    4Line control stops the line

    ARCX signals the main line control PLC, which stops the production line.

  5. Responding

    5A team leader responds

    A team leader comes to the station and resolves the problem.

Line runningLine stopped

Illustration. How the line responds, including when it stops, is set in your line control.

Built for connectors that click

Electrical connectors
Wire-harness and in-vehicle connectors, where a missed click becomes a circuit fault found late.
Snap-fit connectors
Any connector that gives an audible click when it seats.
Automotive first
Starting on vehicle assembly lines. Other manual assembly, such as agricultural equipment, appliances and aerospace, has the same problem.

A separate product

Standardized Work Tracker

The same wearable platform, pointed at a different problem. A wrist wearable and a fixed anchor at the station follow how the work is done and compare it with standard work, without cameras.

LinePartsAnchor12345
  • Standard work
  • Path taken
  • Extra reach, over standard

Illustrative example

Start with one station

  1. Step 1

    Tell us about the station

    The connector, the noise, the build, and how the line is controlled today.

  2. Step 2

    Pilot it

    We run the wearable at one station and measure how it performs on your connectors, in your noise.

  3. Step 3

    Extend it

    Take it to more stations through the same ARCX integration.

The wearable is in development, and we are opening pilot conversations with manufacturers now.

Questions

What is AI Connector Pokayoke?

A wearable that listens for the click of a connector seating, with software that identifies that click and tells the assembler whether the connector is seated. Pokayoke means mistake-proofing: the check happens at the moment of the install, not afterwards.

Where is it worn, and does it get in the way?

On the wrist, so both hands stay free for the work. The assembler does nothing different: seat the connector and look at the wrist.

Does it use cameras?

No. It works from sound and hand motion only.

How does it connect to line control?

Through ARCX, our partner. An ARCX controller is a compact PLC mounted line side. It is the integration into line control, and it is where all the build and assembler information comes from.

Will it work in a loud plant?

Loud plants are the design case. The wearable pairs sound with hand motion, and the software is built to separate a seated connector from other noise. We measure performance on your connectors and in your noise during a pilot, before anything is rolled out.

How accurate is it?

We do not publish an accuracy figure until it has been measured on real connectors in a real plant. A pilot gives you that number for your own line.

Is it available today?

The wearable is in development, and we are opening pilot conversations with manufacturers. Get in touch to talk about your station.

How is the Standardized Work Tracker different?

AI Connector Pokayoke checks one thing at the moment it happens: did this connector seat? The Standardized Work Tracker checks how the whole job is done against standard work. They are separate products on the same wearable platform.

Bring us the connector that is hard to get right.

Or email info@acousticinsight.ca
